Nickel Inconel 601

Nickel Inconel 601

Nickel Inconel 601 is a member of the austenitic nickel-chromium based super alloys. It is used for applications that require extremely high resistance to heat, and very high resistance to oxidation and corrosion at higher temperatures. It has excellent mechanical properties and is easily workable with standard procedures.

Due to its plethora of positive properties, it finds use in harsh environments in different industry applications, especially in places where it is repeatedly exposed to a wide temperature range and in the presence of corrosives, such as acids.

Tech Steel & Materials offers Nickel Inconel 601 in 2 sub-type specifications, each in multiple and customized shapes/forms:

We offer a fully customized line of tube drawing and seamless tubing for Nickel 601. To learn more about our custom tubing services click here: Custom Tubing for Your Unique Application

The Composition (%) of Nickel Inconel 601

The composition of the particular alloy is the following:

Nickel Chromium Iron Aluminum Carbon Manganese Sulfur Silicon Copper
58%-63% 21%-25% Remainder 1%-1.7% 0.10% max 1% max 0.015% max 0.50% max 1% max

Fabrication and Working Instructions

The Inconel 601 alloy can be formed, machined and welded by standard procedures. That said, it is strongly recommended to clean it from oil or paint before heating, as with every other alloy with high nickel content.

A low-sulfur atmosphere is also a must, and also fuels which are very low in sulfur. Even though it is resistant to oxidation, Inconel 601 should be heated in furnaces with a slightly reducing atmosphere.

Strengthening with heat treatment doesn’t work on this alloy. Instead, use of cold work and an annealing treatment is recommended for achieving different ranges of strength and hardness. The Inconel 601 alloy is annealed at 2100°F (1149°C) and then cooled rapidly through the 1000 to 1400°F (540 to 760°C) temperature range to prevent thermal cracking.

Rapid cooling also has no effect on the mechanical properties of Inconel 601, but rapid cooling is still recommended for pickled material in order to avoid sensitization.

Pickling, on the other hand, must be used to produce bright surfaces on parts that have been previously heated, due to the aluminum and chromium content of the Inconel 601 alloy.

Mechanical and Physical Properties of Nickel Inconel 601

Nickel Inconel 601 has good mechanical strength, but its mechanical property changes depending on the form of the material. According to the manufacturer, the optimal temperature for this alloy is 1004°F (540°C) and above for solution-treated condition, and 1004°F (540°C) and below for annealed condition. Being used primarily in high-temperature applications, the Inconel Alloy 601 can retain its high tensile properties at higher temperatures, and it is not embrittled by extended exposure.

Mechanical Properties Imperial Metric
Tensile strength (solution annealed, room temperature) 110000 psi 760 MPa
Yield strength (solution annealed, room temperature) 65300 psi 450 MPa
Elongation at break 42% 42%

Finally, the physical properties of Inconel 601 can be summarized in the following:

Density 8.11 Mg/m3 (0.293 lb/in3)
Melting Range 2480-2571°F (1360-1411°C)
Specific Heat 70°F – 0.107 Btu/lb-°F (21°C – 448 J/kg-°C)
Permeability at 200 oersted
76°F – 1.003 (24°C – 1.003)
-109°F – 1.004 (-78°C – 1.004)
-320°F – 1.016 (-196°C – 1.016)
Curie Temperature <-320°F (<-196°C)

Applications and Common Use Of Nickel Inconel 601

  • High-temperature applications in the automotive industry and aerospace – turbocharger rotors and seals (notable use is Mazda RX-7 third gen), rotary engines (Norton motorcycles), Formula 1 and NASCAR exhaust systems;
  • High-temperature applications in aerospace – gas turbine blades and containment rings, seals and combustors, jet engine igniters, combustion-can liners, and diffuser assembles;
  • Thermal-processing equipment – baskets, trays, and fixtures for annealing, carburizing, carbonitriding, nitriding for industrial-heating applications, and in radiant tubes, muffles, retorts, flame shields, strand-annealing tubes, woven-wire conveyor belts, and electrical resistance heating elements in industrial furnaces;
  • Chemical-processing – insulating cans in ammonia reformers and equipment for nitric acid production;
  • Petrochemical processing – catalyst generators and air preheaters;
  • Pollution-control applications – combustion chambers in solid-waste incinerators;
  • Power-generation field – superheater tube supports grid barriers and ash handling

Other Aspects and Advantages

The nickel alloy has a high degree of metallurgical stability, and it has a complete absence of embrittling intermetallic phases thanks to its internal microstructure.

The high content of nickel and chromium make the Inconel 601 alloy extremely resistant to high-temperature corrosion mechanisms, with resistance to oxidation of up to 2200°F (1200°C).

Unique among similar alloys, it also has resistance to oxide spalling under cyclic thermal conditions. It forms a protective oxide coating that resists scaling even after repeated exposure to temperature. This property of the alloy is linked to the high amounts of nickel and chromium, and also the presence of aluminum, all of which form an extremely protective oxide film on the material.

Nickel Inconel 601 alloy has good resistance to carburization and carbonitriding environments.

Select AMS Number:

AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
AMS 5715 Inconel 601 Nickel N06601
AMS 5715 Custom Tube Inconel 601 Nickel N06601 - Custom Tube AMS 5715 Custom Tube
AMS 5715 Inconel 601 Bar Inconel 601 Nickel N06601 - Inconel 601 Bar AMS 5715 Inconel 601 Bar
AMS 5715 Inconel 601 Forging Inconel 601 Nickel N06601 - Inconel 601 Forging AMS 5715 Inconel 601 Forging
AMS 5715 Inconel 601 Ring Inconel 601 Nickel N06601 - Inconel 601 Ring AMS 5715 Inconel 601 Ring
AMS 5870 Inconel 601 Nickel N06601
AMS 5870 Inconel 601 Plate Inconel 601 Nickel N06601 - Inconel 601 Plate AMS 5870 Inconel 601 Plate
AMS 5870 Inconel 601 Sheet Inconel 601 Nickel N06601 - Inconel 601 Sheet AMS 5870 Inconel 601 Sheet
AMS 5870 Inconel 601 Strip Inconel 601 Nickel N06601 - Inconel 601 Strip AMS 5870 Inconel 601 Strip
